SenseCAP S2100 - LoRaWAN Data Logger by Seeed - The Pi Hut

SenseCAP S2100 - LoRaWAN Data Logger

Name: SenseCAP S2100 - LoRaWAN Data Logger
Brand: Seeed
SKU: 106399
Price: 66.9 GBP
Availability: InStock

SeeedSKU: 106399

£66.90

incl. VAT

excl. VAT

In stock

Awesome Extras

Waterproof Junction Box Kit for S2100 Data Logger by Seeed - The Pi Hut

Seeed Waterproof Junction Box Kit for S2100 Data Logger

£9.70 incl. VAT excl. VAT

SenseCAP CO2, Temperature and Humidity Sensor with RS-485 & SDI-12 by Seeed - The Pi Hut

Seeed SenseCAP CO2, Temperature and Humidity Sensor with RS-485 & SDI-12

£75.90 incl. VAT excl. VAT

SenseCAP S2110 Sensor Builder by Seeed - The Pi Hut

Seeed SenseCAP S2110 Sensor Builder

£19.10 incl. VAT excl. VAT

Seeed Modbus RS485 Vision AI Camera by Seeed - The Pi Hut

Seeed Seeed Modbus RS485 Vision AI Camera

£44.60 incl. VAT excl. VAT

The SenseCAP S2100 LoRaWAN Data Logger is a rugged and adaptable industrial-grade data acquisition unit designed to transmit sensor data to a LoRaWAN network. With support for MODBUS-RTU RS485, analog (4–20mA/0–10V), and GPIO (level or pulse) sensors, it offers broad compatibility with industrial and environmental monitoring equipment. Its single-channel design allows it to operate with one interface at a time, making it ideal for specialised deployments.

This device is engineered for harsh outdoor environments, featuring an IP66-rated enclosure and an operating temperature range of -40°C to +85°C. The internal 19Ah lithium battery supports up to 10 years of operation, while an optional 12V DC input can be used for primary power, with the internal battery acting as a backup. Communication is handled via LoRaWAN® v1.0.3, and the S2100 supports global frequency bands (863–928MHz), offering a typical range of up to 2km in urban environments and up to 10km line-of-sight.

Setup and configuration are straightforward thanks to built-in Bluetooth and the SenseCAP Mate App, which supports OTA (over-the-air) updates and remote configuration. Combined with the SenseCAP Portal, users can manage devices, data, and access keys from a web-based dashboard. MQTT and HTTP APIs are also available for further integration and development.

Reliability has been a major focus in the S2100’s design, with six types of durability testing conducted during development - including temperature cycling, waterproofing, and long-range performance - to ensure the unit performs consistently in field conditions.

The S2100 also supports expansion via the SenseCAP S2110 Sensor Builder, allowing you to connect Grove Sensors directly for rapid prototyping or small-scale LoRaWAN deployments. This opens up DIY possibilities using Seeed's existing Grove ecosystem, without requiring custom code or hardware changes.

Video

Lithium Battery Shipping: Due to courier restrictions, this product can only be shipped within the United Kingdom. With this item in your cart your shipping options will be limited and may cost more than our usual rates. Why?

Features

Strong Compatibility with different Sensors: supports all MODBUS-RTU RS485/Analog (4 ~ 20mA/0~10V) / GPIO(level/pulse) sensors.
Compatible with Worldwide LoRaWAN® Networks: Compatible with LoRaWAN® V1.0.3 protocol and can work with LoRaWAN® gateway. (support the universal frequency plan from 863MHz ~928MHz).
Long Range & replaceable Battery powered: With LoRaWAN® wireless transmission, S2100 supports a 19Ah built-in battery and external 12V DC to supply devices, and an ultra-wide-transmission range of 2km in urban scenes and 10km in line of sight scenes.
Designed to Use in Harsh Environments: -40℃ ~ 85℃ operating temperature and IP66 rated enclosure, suitable for outdoor use, high UV exposure, heavy rain, dusty conditions, etc.
Remote configuration and management: Seeed provides SenseCAP Mate APP and SenseCAP Portal, allows users to remotely manage data and configure.

Specifications

Product Model	SenseCAP S2100
Microcontroller	Wio-E5
Support Protocol	LoRaWAN v1.0.3 Class A
Built-in Bluetooth	App Tool to change parameters and set data conversion algorithm
Long-Range Channel Plan	IN865/EU868/US915/AU915/AS923*
Max Transmitted Power	19dBm
Sensitivity	-136dBm @ SF12 BW=125KHz
Communication Distance	2 to 10km (depending on environment)
IP Rating	IP66
Operating Temperature	-40 to +85 °C
Operating Humidity	0 to 100 %RH (non-condensing)
Device Weight	280g
Battery Life	Up to 10 years**
Battery Capacity	19Ah (non-rechargeable)
Battery Type	Standard D-size SOCl2 Battery

* Every single device can support 7 frequency plans.

** This wireless LoRaWAN sensor supports up to 10 years of battery life, but the actual battery life varies from data upload interval, data payload, and distance between gateways.

** We have updated the battery life table, which should provide you with a better estimate of the actual battery life of your device. We recommend that you refer to the updated table when making any judgment or decision related to the battery life of your device.
