M5Stack ATOM Lite ESP32 Development Kit

M5StackSKU: C008
(18 Reviews)
£9
incl. VAT
excl. VAT
In stock

Awesome Extras

ATOM Matrix ESP32 Development Kit - The Pi HutATOM Matrix ESP32 Development Kit - The Pi Hut
(3 Reviews)
M5StackM5Stack ATOM Matrix ESP32 Development Kit
£15 incl. VAT excl. VAT
ATOMIC Proto Kit - The Pi HutATOMIC Proto Kit - The Pi Hut
(2 Reviews)
M5StackM5Stack ATOMIC Proto Kit
£3.90 incl. VAT excl. VAT
ATOM TailBat - The Pi HutATOM TailBat - The Pi Hut
(2 Reviews)
M5StackM5Stack ATOM TailBat
£9.50 incl. VAT excl. VAT

Tiny IoT development kit, ideal for making embedded smart home devices and smart toys. At only 24x24mm, it's great for fitting into projects where space is at a premium!

For more information and for help getting started, click here

Product Features

  • ESP32-PICO chip
  • Onboard wifi and Bluetooth
  • 4MB of integrated SPI flash memory
  • RGB LED
  • Programmable button
  • Built-in Infra-red LED
  • Six GPIO connectors for attaching to external sensors
  • PH2.0 interface
  • On-board USB-C interface for programming
  • Program Platform: Arduino / UIFlow

Applications

  • Internet of Things terminal controller
  • IoT node
  • Wearable peripherals

Specification

Resources Parameter
ESP32 240MHz dual core, 600 DMIPS, 520KB SRAM, Wi-Fi, dual mode Bluetooth
Flash 4MB
Power Input 5V @ 500mA
Port TypeC x 1, GROVE(I2C+I/0+UART) x 1
PIN Port G19, G21, G22, G23, G25, G33
RGB LED WS2812B x 1
IR Infrared transmission
Button Custom button x 1
Antenna 2.4G 3D Antenna
Operating Temperature 32°F to 104°F ( 0°C to 40°C )
Size 24 x 24 x 10 mm
Weight 12g
Case Material Plastic ( PC )
