Adafruit Metro M7 with AirLift - Featuring NXP iMX RT1011 - The Pi Hut

Adafruit Metro M7 with AirLift - Featuring NXP iMX RT1011

Name: Adafruit Metro M7 with AirLift - Featuring NXP iMX RT1011
Brand: Adafruit
SKU: ADA4950
Price: 28.90 GBP
Availability: InStock

AdafruitSKU: ADA4950

£28.90

incl. VAT

excl. VAT

Only 3 units left

Awesome Extras

USB-A to USB-C Cable - Black - The Pi Hut

The Pi Hut USB-A to USB-C Cable - Black

From £2.25 incl. VAT excl. VAT

STEMMA QT / Qwiic Compatible JST-SH 4-Pin Cable (50mm) - The Pi Hut

The Pi Hut STEMMA QT / Qwiic Compatible JST-SH 4-Pin Cable (50mm)

£0.80 incl. VAT excl. VAT

Premium Male/Male Jumper Wires - 20 x 6" (150mm) - The Pi Hut

The Pi Hut Premium Male/Male Jumper Wires - 20 x 6" (150mm)

£1.70 incl. VAT excl. VAT

Get ready for our fastest Metro ever - the NXP iMX RT1011 microcontroller powers this board with a 500 MHz ARM Cortex M7 processor. There's 8 MB of execute-in-place QSPI for firmware + disk storage and 128KB of SRAM in-chip

Features

NXP iMX RT1011 processor - ARM Cortex M7 processor running at 500 MHz, with 128KB SRAM and high-speed USB
AirLift WiFi Co-processor, with TLS/SSL support, plenty of RAM for sockets, communication is over SPI and has CircuitPython library support ready to go for fast wireless integration
8MB of QSPI XIP FlashPower options - 6-12VDC barrel jack or USB type C
UNO-shape so shields can plug in
Reset button - Click to restart, double-click to enter UF2 bootloader
Boot-mode switches to get into the ROM bootloader (you can always reload code over USB if TinyUF2 gets corrupted somehow)
SWD connector for advanced debugging access.
On/Off switch
STEMMA QT connector for I2C devices
On/User LEDs + status NeoPixel
Works with CircuitPython!
53.2mm x 72mm / 2" x 2.8"
Height (w/ barrel jack): 14.8mm / 0.6"
Weight: 22.5
