M5StickC PLUS2 ESP32 Mini IoT Development Kit

M5StackSKU: K016-P2
£18.90
incl. VAT
excl. VAT
In stock

Awesome Extras

M5Stack M5StickC PLUS ESP32-PICO Mini IoT Development Kit - The Pi HutM5StickC PLUS ESP32-PICO Mini IoT Development Kit - The Pi Hut
M5StackM5Stack M5StickC PLUS ESP32-PICO Mini IoT Development Kit
£24 incl. VAT excl. VAT
Notify me
USB-A to USB-C Cable - Black - The Pi Hut
The Pi HutUSB-A to USB-C Cable - Black
From £2.25 incl. VAT excl. VAT
M5Stack SandwichC Brick - The Pi HutM5Stack SandwichC Brick - The Pi Hut
M5StackM5Stack SandwichC Brick
£1 incl. VAT excl. VAT
M5Stack Dlight Unit - Ambient Light Sensor (BH1750FVI-TR) - The Pi HutM5Stack Dlight Unit - Ambient Light Sensor (BH1750FVI-TR) - The Pi Hut
M5StackM5Stack Dlight Unit - Ambient Light Sensor (BH1750FVI-TR)
£4.08 incl. VAT excl. VAT
M5Stack M5StickC PIR Hat (AS312) - The Pi HutM5Stack M5StickC PIR Hat (AS312) - The Pi Hut
M5StackM5Stack M5StickC PIR Hat (AS312)
£3 incl. VAT excl. VAT

The M5StickC PLUS2 is a refined version of the M5StickC PLUS, featuring the ESP32-PICO-V3-02 chip with built-in WiFi. Packed into its compact size are various hardware components, including infrared, RTC, a microphone, and much more! Its 1.14" TFT screen has a resolution of 135 x 240, driven by the ST7789V2. With an upgraded 200mAh battery and support for HAT and Unit series products, this development tool is versatile and beginner-friendly, making it easy to prototype IoT projects. The M5StickC PLUS2 opens up creative possibilities without overwhelming complexity.

This also comes as a watch kit with accessories, click here to see it in our shop.

Lithium Battery Shipping: Due to courier restrictions, this product can only be shipped within the United Kingdom. With this item in your cart, your shipping options will be limited and may cost more than our usual rates. Why?

Power On:

Wake-up can be started by pressing "BUTTON C" for more than 2 seconds, or an IRQ signal triggered by RTC regularly. After triggering the wake-up signal, the hold(G4) pin needs to be set to a high level (1) in program initialization to maintain the power supply, otherwise the device will enter the shutdown state again.

Power Off:

When there is no USB external power supply, press "BUTTON C" for more than 6 seconds; Or when there is no USB external power supply, set HOLD(GPIO4)=0 in the program operation, that is, to achieve power off.

Features

  • ESP32-­PICO-­V3-­02-Base，support WiFi
  • Built-in 6-Axis IMU
  • IR transmitter
  • Microphone
  • RTC
  • Buttons, LCD(1.14 inch)
  • Built-in Lithium Polymer Battery@200mAh
  • Extendable Socket
  • Built-in Passive Buzzer
  • Wearable & Wall mounted
  • Compatible with multi-platform development:

Specifications

Resources Parameters
ESP32 ESP32-PICO-V3-02
240MHz dual core,support wifi,2 MB SPI PSRAM,8 MB SPI flash
PSRAM 2 MB PSRAM
Flash 8 MB flash
Power Input 5V @ 500mA
Port TypeC x1, GROVE (I2C+I/0+UART) x1
LCD screen 1.14", 135 x 240 Colorful TFT LCD, ST7789v2
Button Custom button x3
LED Green LED
MEMS MPU6886
Buzzer Built-in buzzer
MIC SPM1423
RTC BM8563
Battery 200mAh @ 3.7V
Antenna 2.4G 3D Antenna
PIN port G0, G25/G36, G26, G32, G33
Operating Temperature 0°C to 60°C
Case Material Plastic (PC)
Product Size 48 x 25 x 13mm
Package Size 114 x 64 x 23mm
Product Weight 17g
Package Weight 24.8g

Driver Installation

Click the link below to download the driver that matches the operating system. There are currently two driver chip versions, CP34X (for CH9102) driver compressed package. After decompressing the compressed package, select the installation package corresponding to the number of operating systems to install. If the program cannot be downloaded normally (the prompt is overtime or failed to write to target RAM), you can try to reinstall the device driver.

Driver Name Applicable Driver Chip Download Link
CH9102_VCP_SER_Windows CH9102 Download
CH9102_VCP_SER_MacOS v1.7 CH9102 Download

Resources

Package Contents

  • 1x M5StickC Plus2
