The M5Stack Fader Unit combines a smooth 35mm slider potentiometer with 14 individually addressable RGB LEDs, making it ideal for lighting control, audio adjustment, and interactive input projects.
The M5StackFader Unit is a slider potentiometer/fader integrated with indicator lights, designed with a 35mm travel slider potentiometer and 14 x SK6812 programmable RGB lights.
The fader features centre positioning, and its excellent sliding damping provides smoother, more stable, and precise control. The integrated LEDs support digital addressing, meaning you can individually control the colour and brightness of each LED to achieve various lighting effects.
This product is suitable for applications such as lighting and music control.
Features
Centre positioning
Comfortable sliding damping
Single 10kΩ adjustable resistor
Programmable RGB lights
GROVE interface
Development platforms:
Arduino, UIFlow
Specifications
Fader Travel
35mm
Fader Handle Length
10mm
Single Resistor
10kΩ
Output Voltage
0-3.3V (when powered by 5V)
RGB LED
14x SK6812 programmable RGB lights
Working Current
90.04mA (light brightness at 50%, fader max output)
