Olimex RP2350PC

The Olimex RP2350PC is a compact all-in-one RP2350 computer with video output, USB host support, audio, battery charging, and built-in classic 8-bit computer emulation, making it ideal for retro computing, gaming, and embedded projects.

The Olimex RP2350PC is a compact all-in-one computer built around the RP2350, featuring 16MB of SPI flash, 8MB of PSRAM, four USB 2.0 host ports, stereo audio with an integrated codec and amplifier, DVI/HDMI video output, a Li-Po charger, a UEXT expansion connector, and a USB-C power input.

Preloaded with the Reload emulator, the RP2350PC can emulate a range of classic 8-bit computers, including the Apple II, Apple IIe, Oric Atmos, Pravetz, and Puldin. It also supports the Total Replay collection, giving you access to thousands of classic Apple II games.

The USB host ports allow you to connect a variety of peripherals, including USB flash drives, keyboards, and USB gamepads. USB gamepads can also emulate an Apple joystick, making it easy to enjoy classic games with modern controllers.

Features

• RP2350B Dual Arm Cortex-M33 or dual Hazard3 RISC-V processors @ 150MHz
• 520 KB on-chip SRAM
• 16MB SPI Flash
• 8MB of PSRAM
• DVI/HDMI output
• 4x USB hosts
• Audio codec with stereo audio amplifier
• PWM Stereo Audio generation
• Audio 3.5mm Line-in
• Audio 3.5mm headphones connector
• Two JST2.0 connectors for left and right speaker
• USB-C connector for power supply
• USB-C connector for programming
• Two UEXT connectors
• Power switch
• RP2350B reset and programming bootloader button
• Four mounting holes 3.3mm diameter
• Lipo charger and JST 2.0 connector
• MicroSD card
• Dimensions: 85 x 65mm

Resources

• User manual
• Schematic in PDF format
• KiCAD source files
• Reload emulator for Apple II, Apple IIe, Oric Atmos, PULDIN601
• API library by Paul Robson
• Default firmware.uf2 at our FTP
• What is an UEXT?

Package Contents

• 1x Olimex RP2350PC
• 4x Rubber feet
