Gravity: TCS3430 Tristimulus Color Sensor

DFRobotSKU: SEN0404
Price:
Sale price £16.80
incl. VAT
excl. VAT
Stock:
Only 6 units left
Quantity:

Awesome Extras

ArduinoArduino Uno Rev3
Sale price £24.50 incl. VAT excl. VAT
DFRobotGravity: I2C OLED 128x64 Display
Sale price £14.90 incl. VAT excl. VAT

TCS3430 XYZ Tristimulus Color Sensor employs the new generation of TCS3430 spectral sensor IC launched by the well-known AMS company. It features advanced digital ambient light sensing (ALS) and CIE 1931 tristimulus color sensing (XYZ). Each of the channels has a filter to control its optical response, which allows the device to accurately measure ambient light and sense color. These measurements are used to calculate chromaticity, illuminance, and colour temperature, all of which are used to support various potential applications.

You can learn more about the CIE 1931-XYZ system here: https://en.wikipedia.org/wiki/CIE_1931_color_space

Features

  • XYZ Tristimulus Filter
  • Capable of ±10% illuminance and correlated color temperature accuracy
  • Wide dynamic range and high sensitivity
  • Programmable gain and integration time

    Specifications

    • Power Supply: 3.3V~5V
    • Operating Current: <5mA
    • LED Operating Current: <15mA
    • I2C Address: 0x39
    • Operating Temperature Range: -30°C~85°C
    • Dimension: 22 x 27mm

    Resources

    Package Contents

    • 1x Gravity: TCS3430 Tristimulus Colour Sensor
    • 1x Gravity-4P I2C/UART Sensor Connector
