Bluno Link - USB Bluetooth 4.0 (BLE) Dongle

DFRobotSKU: TEL0087
£9.60
incl. VAT
excl. VAT
Only 2 units left
Add bluetooth 4.0 to your PC, Mac directly with this USB BLE-Link. It uses the USB package which is compact and compatible with v2.1 and earlier, and also supports the latest v4.0/Bluetooth Low Energy. Now you could use this adapter to receive/transmit data.

With two USB-BLE Link users can do point-to-point wireless transparent transmission, master-slave machine setting, and wireless programming. It can also work as a PC BLE wireless programming adapter. Comaptible all DFRobot BLE series modules: i.e. Bluno - An Arduino Bluetooth 4.0 (BLE) Board, Romeo BLE (Arduino Robot Control Board with Bluetooth 4.0), etc

JavaScript display

Specification

  • Bluetooth chip: TI CC2540
  • Frequency: 2.4GHz
  • Pin Layout: Compatible with Xbee pinout
  • Transfer rate: ≤1Mbps
  • Modulation: GFSK, bluetooth low power, V4.0
  • Sensitivity: -93dB
  • Input Voltage: +3.3 DC
  • Operating temperature： -10 ℃ ~ +85 ℃
  • Transmission distance: 5~15m in free space
  • Size: 32mm * 16mm(1.26"*0.63")
  • support AT command to debug the BLE
  • support master-salve switch
  • support transparent transmission serial port
  • support bluetooth remote update the Arduino program

Documents

Shipping List

  • USB BLE-LINK x1
