The AnsmannHome Charger HC120PD UK is a compact and intelligent USB-C wall charger designed for fast and reliable charging of smartphones, tablets, and other USB-powered devices.
Delivering up to 20W of power through its USB-C port, it supports a wide range of charging standards including PD3.0, PPS, Quick Charge, AFC, FCP, and SCP for broad device compatibility.
The charger features a universal 100-240V AC input for worldwide use and includes built-in protection against short circuits, overvoltage, and overcurrent. It is IP20 rated, CE marked, and supplied in simple white box packaging.
Features
Single USB-C port with up to 20W power output
Input: 100-240V AC at 50/60Hz for worldwide use
Output: 3.3-12V at 3A maximum
Compatible with PD3.0, PPS, QC4+, QC3.0, QC2.2, AFC, FCP, SCP, DCP, Apple 2.4A and Samsung 5V-2A protocols
Multi-protection against short circuit, over voltage and over current
IP20 ingress protection and CE marked
Economical and intelligent charging solution
Specifications
Input Voltage
110V-240V AC
Max. Input current
0.5A
AC frequency
50/60 Hz
Port
USB-C
Output voltage
3.3V-12V DC
Max. output current
3A
Maximum power
20W
Functions
Over voltage protection, over current protection, short circuit protection
