This HDMI to USB 3.0 adapter is used for video capture in gaming, streaming, and cameras. It has a 4K input (30Hz) and a 1080P output (30Hz/60Hz) with ultra-low latency, giving you a smooth transmission without lag. It supports a wide variety of devices including a Raspberry Pi, smartphone, game console, set-top box, laptop, and many more!

Supporting multiple systems including Windows, Linux, MacOS and Android, this adapter is easy to use, fast, reliable and is available to use in many different devices.

Features

  • Compatible with HDMI 1.4B
  • Support DVI1.0
  • Support HDCP1.4
  • Support RGB444/YCBCR422/YCBCR444/YCBCR420
  • Support colour depth 24/30/36-bit mode
  • Support CEA-861/CEA-861-F video format
  • Maximum supported resolution: 4K (3840x2160@30Hz)

USB Output

  • Built-in USB 3.0 device
  • Compatible with USB 2.0 device mode
  • USB video complies with the UVC 1.0 protocol
  • Support YUV422 and MJPEG mode
  • Maximum supported resolution: 1080P (1920x1080@60Hz)
  • Support user-define resolution
  • USB audio is compliant with the UVC1.0 protocol

Specifications

INPUT HDMI
Input resolution up to 4K (3840x2160@30Hz)
HDMI 1.4B compliant
OUTPUT USB3.0 USB2.0
Output resolution up to 1080P Output resolution up to 1080P
(1920*1080@60Hz) (1920*1080@30Hz)
Supports YUV422 and MJPEG modes Supports YUV and JPEG modes
UVC1.0 and UAC1.0 protocol compliant
TRANSMISSION LATENCY As low as 50ms 100~150ms
AUDIO Default 48KHz stereo output Default 96KHz stereo output
SYSTEM SUPPORT Windows, Linux, macOS, Android
SOFTWARE SUPPORT OBS, Potplayer, QuickTime, XSplit, etc.

Resources

Package contents

  • 1x HDMI to USB Adapter
