PIR Stick for Tiny FX

PimoroniSKU: PIM749
Price:
Sale price £7.50
incl. VAT
excl. VAT
Stock:
Coming Soon
Notify me

Awesome Extras

Tiny FX - LED Effects ControllerTiny FX - LED Effects Controller
PimoroniTiny FX - LED Effects Controller
Sale priceFrom £15 incl. VAT excl. VAT
Debug Cable for Raspberry Pi Pico - The Pi HutDebug Cable for Raspberry Pi Pico - The Pi Hut
The Pi HutDebug Cable for Raspberry Pi Pico
Sale price £1.50 incl. VAT excl. VAT
3-pin JST-SH cables for Grow moisture sensors (pack of 3) - The Pi Hut3-pin JST-SH cables for Grow moisture sensors (pack of 3) - The Pi Hut
Pimoroni3-pin JST-SH cables for Grow moisture sensors (pack of 3)
Sale priceFrom £1.80 incl. VAT excl. VAT
Six Port Expansion Board for Tiny FX (Pack of Two)Six Port Expansion Board for Tiny FX (Pack of Two)
PimoroniSix Port Expansion Board for Tiny FX (Pack of Two)
Sale price £3.90 incl. VAT excl. VAT

A passive infrared (PIR) sensor stick that gives your Tiny FX projects the ability to trigger effects when motion is detected.

Humans and other warm objects emit heat in the form of IR radiation. This sensor uses changes in IR radiation to detect motion in front of it and sends out a simple digital signal that can be read by any microcontroller.

We designed PIR Stick to handle the very important business of triggering motion effects on our Tiny FX models so it comes with a cable that will let you plug it straight into the three-pin connector on Tiny FX. If you're planning on using it with another microcontroller, you'll probably want to pick up a JST-SH to DuPont cable to connect it up*. We also have loooooong JST-SH to JST-SH cables available if you want to position your PIR Stick further away from your model.

Click here to view everything Tiny FX!

Notes

  • Tiny FX Board is NOT included
  • PIR Stick has no reverse polarity protection, so if you've wired it up yourself double check your wiring to make sure power is connected to + and ground is connected to -. It will get quite hot very quickly if you get the polarity wrong!
  • The sensor has a preferred detection direction. For best results in a typical room, orient the stick vertically so that it can detect motion passing it horizontally.

Features

  • Senba S18-L262B-2 Digital Pyroelectric Infrared Sensor (Datasheet)
  • Onboard potentiometer for sensitivity adjustment (clockwise to increase, anti-clockwise to decrease)
  • Includes 3-pin JST-SH cable (150mm long, approx)

Specifications

Input Voltage 2.2 V – 3.7 V
Current (max) 14 µA
Logic Output 3.3 V / 0 V
Delay Time 0s
Lock Time 2s
Field of View 80° H, 55° V (stick oriented vertically)
Sensing Range 3 - 5 m

Resources

Pinout

  • '+': Power In (3.7 V max)
  • 'OUT': Data
  • '-': Ground

Package Contents

  • 1x PIR Stick for Tiny FX
  • 3-pin JST-SH Cable
