Update: this adapter works with the V3.0 Complete Cluster Enclosure. It is not intended to work with the U6243 version of the Complete Cluster case we stock (however some customers have reported that it works fine...your mileage may vary!).
This fan adapter board is for the U6260 Upgraded Complete Enclosure for Raspberry Pi Clusters V3.0. Equipped with a USB Type-C and Micro-USB interface, it can work with the Raspberry Pi 4, 3 and all standard models.
The adapter is a simple plug-and-play item, outputting 5V power via the pin headers for the 80mm fans. Just pop it into your Raspberry Pi's power port as shown below.
Note: Please pay attention to the positive and negative poles when connecting the fan. The red wire represents the positive pole and the black wire represents the negative pole.
- 1x Fan adapter
Cluster case, fans and Raspberry Pi not included
