Designed for cellular and low-power wide-area network applications, this compact high-gain antenna supports 4G, 3G, 2G, and LPWA connectivity.
LPWA stands for Low-Power Wide-Area, used by networks such as NB-IoT, LTE-M, LoRaWAN and Sigfox, designed for long-range, low-power IoT communication.
The antenna features a standard SMA-Male connector with inner pin, a 90° adjustable design for flexible positioning and a tough ABS enclosure.
Operating across 698–960MHz and 1710–2690MHz frequency bands, the antenna provides up to 4.0dBi ± 0.5dBi gain, vertical polarisation, and a standard 50Ω output impedance.
Features
Compatible with 4G, 3G, 2G, and LPWA networks
698–960MHz and 1710–2690MHz frequency coverage
4.0dBi ± 0.5dBi gain
90° adjustable antenna design
Vertical polarisation
SMA connector with inner pin
Compact 170mm length
Durable ABS housing
Specifications
Network support
4G/3G/2G/LPWA
Frequency range
698–960MHz / 1710–2690MHz
Gain
4.0dBi ± 0.5dBi
VSWR
≤3.0
Polarisation
Vertical
Output impedance
50Ω
Connector
SMA-Male
Length
170mm
Material
ABS
Colour
Black
Weight
16g
Package Contents
1x 4G/3G/2G/LPWA External Antenna
