3.4" DSI Round Touch Display (800x800)

Name: 3.4" DSI Round Touch Display (800x800)
Brand: Waveshare
SKU: WAV-24321
Price: 79.90 GBP
Availability: InStock

WaveshareSKU: WAV-24321

£79.90

incl. VAT

excl. VAT

Only 7 units left

Compatible with:

Awesome Extras

Raspberry Pi 4 Model B Starter Kit - The Pi Hut

The Pi Hut Raspberry Pi 4 Model B Starter Kit

From £59.70 incl. VAT excl. VAT

USB-A to USB-C Cable - Black - The Pi Hut

The Pi Hut USB-A to USB-C Cable - Black

From £2.25 incl. VAT excl. VAT

Adafruit CSI or DSI Cable Extender Thingy for Raspberry Pi - The Pi Hut

Adafruit Adafruit CSI or DSI Cable Extender Thingy for Raspberry Pi

£2.90 incl. VAT excl. VAT

This 3.4" round touch display is a great way to add a front-end interface to many different projects!

The display has a 170° wide viewing angle that provides an excellent display performance along with a 10-point capacitive touch screen that allows you to easily zoom, rotate, swipe, drag, double tap or use other gestures with up to ten fingers on the screen at the same time (OS-dependent). It has a colourful 800x800 resolution, a tough glass panel, and support for Raspberry Pi boards.

Note: some CM3/3+/4 baseboards require an extra adapter cable, found here

Features

3.4" IPS round display with a hardware resolution of 800×800
10-point capacitive touch control, up to 6H hardness toughened glass panel
Optical bonding technology for clearer imaging
Directly drive LCD via Raspberry Pi's DSI interface, refresh rate up to 60Hz
Raspberry Pi OS system driver is provided for use with Raspberry Pi
Support Pi 4B/3B+/3A+, some CM3+/4 need to be used with an adapter cable
Adjust the backlight via the software

What's Onboard

Specifications

Resolution	800×800
Display Port	DSI
Display Panel	IPS
View Angle	170°
Touch Type	Capacitive
Touch Port	I2C
Toughened Glass Panel	Y
Optical Bonding	Y
Speaker	N
Signal Output	N
