Maker Advent Calendar Day #5: Hear my Code!
Welcome to day five of your 12 Projects of Codemas Advent Calendar. Today we’ll be making sounds with our code using the custom buzzer you've just discovered in your box!
The buzzer is nice and easy to wire into our circuit, using just two pins with no other components required, yet can add SO much to a project! Adding audible feedback for errors, button presses and other actions gives your project a whole new dimension.
Let's make some noise!
Box #5 Contents
In this box you will find:
- 1x Custom pre-wired buzzer with male jumper wire ends
Today we'll be using our buzzer in a few different ways, first for simple beeps and tones, then combining with our potentiometer to control the volume, then finally something a little more advanced where we use different frequencies to generate festive tones!
This particular buzzer works with PWM signals to allow you to generate different tones, so we'll be tapping back into everything we learned about PWM in yesterday's box. It's almost like we planned this...
Construct the Circuit
Remember to unplug your Pico from your USB port before amending the circuit!
We'll be using the potentiometer from yesterday's box to control our buzzer in a few moments, so leave your circuit in place as it is. We just need to add our buzzer and we're good to go.
This is one of the easier components to work with as we've included a custom pre-wired buzzer with male jumper wire ends.
Simply push the red wire into GPIO 13 (physical pin 17) and the black wire into the GND pin next to it (physical pin 18). The Pico pin map is always on hand if you need to check it.
Activity 1: Let's buzz!
Our buzzer can generate different tones based on the PWM frequency and duty cycle we use in our code - this should sound familiar as we covered PWM yesterday.
PWM Frequency and Duty Cycle with Buzzers
The frequency here changes the tone of the buzzer - we find that our ears can detect changes in the tone when using values between 10 and 10000.
The Duty Cycle sets the volume of the buzzer. The range is technically 0 to 65535 in MicroPython, however we find that values below 5000 are very difficult for our ears to hear. A duty of 10000 appears to be the sweet spot for our buzzer.
If you want to silence the buzzer in your code, just set the duty to 0 - easy!
Now we know what the PWM values do here, let's try a quick example where we sound the buzzer for a few seconds.
The example below includes the same ingredients you're now becoming familiar with - imports, pin setup (with PWM), PWM duty cycle and frequency - so there's nothing new or scary here, and our usual slightly-excessive code commentary tells you what each line is doing!
We set up the pin for the buzzer, then assign a frequency (1000) and finally set the PWM duty (volume) to 10000 to for a second, and then back down to 0 to mute it. Nice and easy!
Copy the example over to Thonny and give it a go:
# Imports from machine import Pin, PWM import time # Set up the Buzzer pin as PWM buzzer = PWM(Pin(13)) # Set the buzzer to PWM mode # Set PWM frequency to 1000 buzzer.freq(1000) # Set PWM duty buzzer.duty_u16(10000) time.sleep(1) # Wait 1 second # Duty to 0 to turn the buzzer off buzzer.duty_u16(0)
Now try changing that frequency number to 300 and see what happens. Did the tone go lower? You can try higher values too, but eventually you’ll go too high (around 10000) and it won’t work/your human ears won’t hear it.
Activity 2: Changing tones
Here's another simple example just to show you how easy it is to change the tone on your buzzer from one to another.
Here we start with a frequency of 1000 for one second and then drop it down to 500 for one second.
Give it a try and hear it for yourself:
# Imports from machine import Pin, PWM import time # Set up the Buzzer pin as PWM buzzer = PWM(Pin(13)) # Set the buzzer to PWM mode # Set PWM duty buzzer.duty_u16(10000) # Set PWM frequency to 1000 for one second buzzer.freq(1000) time.sleep(1) # Set PWM frequency to 500 for one second buzzer.freq(500) time.sleep(1) # Buzzer off buzzer.duty_u16(0)
Activity 3: Potentiometer Volume Control
Let’s use one of the previous components to control the volume of the buzzer. This one's a bit noisy and not perfect (the sound can distort or cut out at high levels) but it's a fun project to try out! If you find the buzzer a bit loud or harsh, you can always place some sticky tape or a blob of Blu-tack over the hole to calm it down.
The readings from the potentiometer are between 0 and 65535, and our buzzer duty (volume) uses the same range, so we can use the potentiometer readings to directly control the duty - handy!
In the example below, in each while loop we take a reading from the potentiometer and store it in a variable called 'reading' (just like we did yesterday in activity 3) and then we use this variable as the buzzer duty value (instead of adding a number there ourselves).
A little warning - this example will never turn the buzzer off even if you stop the program as it's just a quick, basic example for us to get familiar with buzzer control. You can unplug the USB cable to stop the noise or just move on to the next activity.
# Imports from machine import Pin, PWM, ADC import time # Set up the Buzzer and Potentiometer potentiometer = ADC(Pin(27)) buzzer = PWM(Pin(13)) # Set the buzzer to PWM mode reading = 0 # Create a variable called 'reading' and set it to 0 while True: # Run forever time.sleep(0.01) # Delay reading = potentiometer.read_u16() # Read the potentiometer value and store it in our 'reading' variable buzzer.freq(500) # Frequency to 500 buzzer.duty_u16(reading) # Use the reading variable as the duty print(reading) # Print our reading variable
Activity 4: Festive Jingle!
How about a little festive tune with our buzzer? By changing the frequency between each pause we can create a tune that resembles a popular festive jingle!
A nice way of doing this is to define each musical note frequency as a variable using the note name, which will make our code easier to write, read and review. We've covered variables before so this should be familiar. We've also used a variable for the volume (duty cycle) as, again, it makes our code a little more human. Don't worry, we've included the tone values for the jingle below for you.
The example below is purposely inefficient and uses a LOT of lines, mostly because each section of the jingle includes lines to turn the volume on then off as well as delays. Try this first, then we'll move on to a nicer way of doing things in the next activity.
We've included commentary on the first jingle block of code to show you what we're doing here.
Tip: This is a simple buzzer, so it doesn't quite have the smooth sound that a normal speaker will create. The buzzer can sound a little more 'Nightmare Before Christmas' than 'Elf'!
# Imports from machine import Pin, PWM import time # Set up the Buzzer pin as PWM buzzer = PWM(Pin(13)) # Set the buzzer to PWM mode # Create our library of tone variables for "Jingle Bells" C = 523 D = 587 E = 659 G = 784 # Create volume variable (Duty cycle) volume = 10000 # Play the tune # "Jin..." buzzer.duty_u16(volume) # Volume up buzzer.freq(E) # Set frequency to the E note time.sleep(0.1) # Delay buzzer.duty_u16(0) # Volume off time.sleep(0.2) # Delay # "...gle" buzzer.duty_u16(volume) buzzer.freq(E) time.sleep(0.1) buzzer.duty_u16(0) time.sleep(0.2) # "Bells" buzzer.duty_u16(volume) buzzer.freq(E) time.sleep(0.1) buzzer.duty_u16(0) time.sleep(0.5) # longer delay # "Jin..." buzzer.duty_u16(volume) buzzer.freq(E) time.sleep(0.1) buzzer.duty_u16(0) time.sleep(0.2) # "...gle" buzzer.duty_u16(volume) buzzer.freq(E) time.sleep(0.1) buzzer.duty_u16(0) time.sleep(0.2) # "Bells" buzzer.duty_u16(volume) buzzer.freq(E) time.sleep(0.1) buzzer.duty_u16(0) time.sleep(0.5) # longer delay # "Jin..." buzzer.duty_u16(volume) buzzer.freq(E) time.sleep(0.1) buzzer.duty_u16(0) time.sleep(0.2) # "...gle" buzzer.duty_u16(volume) buzzer.freq(G) time.sleep(0.1) buzzer.duty_u16(0) time.sleep(0.2) # "All" buzzer.duty_u16(volume) buzzer.freq(C) time.sleep(0.1) buzzer.duty_u16(0) time.sleep(0.2) # "The" buzzer.duty_u16(volume) buzzer.freq(D) time.sleep(0.1) buzzer.duty_u16(0) time.sleep(0.2) # "Way" buzzer.duty_u16(volume) buzzer.freq(E) time.sleep(0.1) buzzer.duty_u16(0) time.sleep(0.2) # Duty to 0 to turn the buzzer off buzzer.duty_u16(0)
Activity 5: Festive Jingle using Functions
Let's improve the very long code above by introducing something new - functions!
Functions are blocks of code that you can create and then call (use) at any time in your program. They're great for repetitive blocks of code as it keeps your program short and efficient (which can be important if your microcontroller has limited storage).
Let's explain how functions work before we move on...
Writing a function
Below is an example of a simple function that prints 3 lines. We create a function by writing 'def' followed by a space and then the name we want to give our function (no spaces in the function name) .
We've called ours 'myfunction'. You then add brackets (parentheses) at the end which can include any arguments if required (we're not using any in this example but we cover them in a moment) followed by a colon (:).
Indentation is important again here - everything under the 'def' line must be indented to indicate that it's part of the function:
def myfunction(): print("This") print("is a") print("function")
So now that we have a function, how do we use it, and why is it better than just writing the code?
We can call (use) the function by simply using the function name followed by the brackets, like this:
So why is this better? Let's look at two examples below where we want to print a set of strings three times. Both of the following examples have the exact same outcome (try them yourself) however the code using functions is shorter.
It might not look like much in this example, however in large projects this can save a LOT of lines in your code. It also makes it a lot easier to update your code as you only have to amend the one function - not every part of your program.
Example without a function
print("This") print("is a") print("function") print("This") print("is a") print("function") print("This") print("is a") print("function")
Example with a function
def myfunction(): print("This") print("is a") print("function") myfunction() myfunction() myfunction()
We mentioned arguments earlier so let's talk about them quickly before we get into our jingle example.
Arguments are optional in functions. They allow you to pass information into your function, if needed. We pass the information to the function when we call it - that might be a bit confusing so let's jump to an example so you can see it working.
In the example below our function prints three lines again, but this time we include arguments asking for the first name, middle name and surname - as we might want to change the names each time we call this function. Those arguments are used in the print lines as you can see below:
def myfunction(first,middle,last): print(first) print(middle) print(last)
Now, to call the function AND pass the names on to it, we add the names in the same places inside the brackets (making sure we enter them inside inverted commas as we're dealing with strings here):
Try this yourself, then try adding a fourth argument and printing a fourth line to go with it.
Now we know how functions work, let's apply them to our jingle example to see if we can reduce the length of the code.
The example below uses a function called playtone to handle all of the volume changes, delays and notes. All you have to do is add the arguments for each.
Our arguments are:
- note - the note to use
- vol - the volume
- delay1 - the first time.sleep period
- delay2 - the second time.sleep period
The code is roughly half the number of lines and does the same thing - much better!
# Imports from machine import Pin, PWM import time # Set up the Buzzer pin as PWM buzzer = PWM(Pin(13)) # Set the buzzer to PWM mode # Create our library of tone variables for "Jingle Bells" C = 523 D = 587 E = 659 G = 784 # Create volume variable (Duty cycle) volume = 32768 # Create our function with arguments def playtone(note,vol,delay1,delay2): buzzer.duty_u16(vol) buzzer.freq(note) time.sleep(delay1) buzzer.duty_u16(0) time.sleep(delay2) # Play the tune playtone(E,volume,0.1,0.2) playtone(E,volume,0.1,0.2) playtone(E,volume,0.1,0.5) #Longer second delay playtone(E,volume,0.1,0.2) playtone(E,volume,0.1,0.2) playtone(E,volume,0.1,0.5) #Longer second delay playtone(E,volume,0.1,0.2) playtone(G,volume,0.1,0.2) playtone(C,volume,0.1,0.2) playtone(D,volume,0.1,0.2) playtone(E,volume,0.1,0.2) # Duty to 0 to turn the buzzer off buzzer.duty_u16(0)
Bonus - More notes!
Chris E kindly added a comment below providing a nice full list of notes (including sharps). Look up your favourite songs, use these notes and get creative. Thanks Chris!
- A = 440
- As = 466
- B = 494
- C = 523
- Cs = 554
- D = 587
- Ds = 622
- E = 659
- F = 698
- Fs = 740
- G = 784
- Gs = 830
Day #5 Complete!
We've covered lots today fellow makers, pat yourselves on the back!
As we cover more advanced topics such as functions, you may find that you need to refer back to these days to refresh your memory later on - and that's absolutely normal! Even the most seasoned professional programmers have to use search engines regularly (some even admit it!).
So what did we cover on day #5? Today you have:
- Built a circuit with a buzzer, your first audio component
- Learnt how to use the buzzer with MicroPython and the Pico
- Learnt about PWM frequencies and duty cycle with buzzers
- Used analogue inputs to control audio volume using PWM
- Created a festive jingle with MicroPython
- Learnt how to use functions to make your code easier to manage and more efficient
Keep your circuit safe somewhere until tomorrow (don't take anything apart just yet).
