SparkFun Current Sensor Breakout - INA169

SparkfunSKU: SEN-12040
£10.90
incl. VAT
excl. VAT
Only 11 units left

Awesome Extras

Arduino Uno Rev3 - The Pi HutArduino Uno Rev3 - The Pi Hut
ArduinoArduino Uno Rev3
£24.50 incl. VAT excl. VAT
Premium Male/Male Jumper Wires - 20 x 6" (150mm) - The Pi HutPremium Male/Male Jumper Wires - 20 x 6" (150mm) - The Pi Hut
The Pi HutPremium Male/Male Jumper Wires - 20 x 6" (150mm)
£1.70 incl. VAT excl. VAT
Notify me
Half-Size Breadboard - WhiteHalf-Size Breadboard - White
The Pi HutHalf-Size Breadboard - White
£3 incl. VAT excl. VAT

The INA169 is a “high-side current monitor,” which means that you place a resistor (a “shunt resistor”) on the positive power rail and the INA169 measures the voltage drop across that resistor. The INA169 outputs a small current based on the measured voltage drop. If you place a resistor from the output of the INA169 to ground, you can measure the voltage at the output.

Input common-mode and power supply voltages are independent and can range from 2.7V to 60V on the INA169 and quiescent (sleep) current is only 60uA.
