Kailh Mechanical Key Switch - Linear Black - Single Piece

Name: Kailh Mechanical Key Switch - Linear Black - Single Piece
Brand: The Pi Hut
SKU: ADA5124
Price: 0.90 GBP
Availability: InStock

The Pi HutSKU: ADA5124

£0.90

incl. VAT

excl. VAT

Only 4 units left

Awesome Extras

Kailh Mechanical Key Switches - Linear Black - 10 pack - The Pi Hut

The Pi Hut Kailh Mechanical Key Switches - Linear Black - 10 pack (Cherry MX Black Compatible)

£6.90 incl. VAT excl. VAT

Adafruit NeoKey Trinkey - USB NeoPixel Mechanical Key Switch - The Pi Hut

Adafruit Adafruit NeoKey Trinkey - USB NeoPixel Mechanical Key Switch

£6.90 incl. VAT excl. VAT

NeoKey FeatherWing - Two Mechanical Key Switches with NeoPixels - The Pi Hut

Adafruit NeoKey FeatherWing - Two Mechanical Key Switches with NeoPixels

£4.50 incl. VAT excl. VAT

For crafting your very own custom keyboard, a Kailh Black Linear mechanical key switches is deeee-luxe! With smooth actuation and Cherry MX compatibility, they're lovely when you want a linear tactile keystroke with a snappy feel and an audible click when pressed.

Type: Clicky tactile
Operating force: 50 gf (+/-10 gf)
Tactile force: 60 gf (+/-15 gf)
Pretravel: 1.9 mm (+/- 0.3 mm)
Pressure point: 1.7 mm
Total travel: 4.0 mm (+/- 0.4 mm)
Reset point: 1.8 mm

Comes as a single key switch. No keycaps or extras. Please note this is not a BOX stem switch. If you need a bunch we recommend getting our 10 packs as they're less expensive that way.

Use these with our NeoKey boards, such as the Socket Breakout and the FeatherWing.
They work great with mechanical key sockets if you want to avoid soldering.
We also have MX-compatible keycaps to snap right on.
