600-6000MHz 5G Antenna

These 5G antennas are designed for 5G modules and equipment that require high efficiency and peak gain to deliver excellent throughput for access points, terminals, and routers on all major cellular (5G/4G/3G/2G) frequency bands in the world. With strong stability, it can effectively enhance WiFi and 5G signals, transmit and receive signals, and improve network quality. The module supports 90° bending, flexible pointing, and is backward compatible with 5G/4G/3G/2G cellular applications, such as 5G, LTE, GSM, UMTS, Wi-Fi, etc.

• Frequency: 600MHz-6000MHz
• Impedance: 50Ω
• Standing Wave Ratio: ＜3
• Gain: 5dBi
• Connector: SMA
• Connection Wire: 11.5mm, IPEX4 generation
• Operating Temperature: -40℃-85℃
• Humidity: non-condensing 65°C, 95%RH
• Size: 47mm in diameter, 30mm in height

• 600-6000MHz 5G Antenna x1
