RGB Full-Colour LED Matrix Panel - 3mm Pitch, 64x32 Pixels
Price:
Sale price
£22.10
Stock:
Awesome Extras
Create a compact colourful display with text, shapes and sequences with this 64x32 3mm pitch RGB LED Matrix panel from Waveshare.
This LED matrix panel contains 2048 individual RGB LEDs which you can control with your favourite compatible microcontroller. The matrix has 64x32 LEDs with a 3mm pitch, suitable for text, animations and more.
The 192x96mm panel includes two HUB75 headers for data, one for input and another for output, which allows you to chain multiple panels together for even larger displays - just keep an eye on current usage and ensure you have an adequate power supply. Power is fed to the unit via the central VCC/GND header.
The LED matrix comes with cables and accessories (see the image below under the Package Contents section). The product wiki includes some demo code and wiring instructions to help you get started with a Raspberry Pi Pico, Arduino Mega and ESP boards!
A 5V 2.5A power supply is recommended.
Need a different size?
We offer these Waveshare LED matrix units in different sizes with different LED pitch layouts, allowing you to find the right option for your specific project - check out the Waveshare range here or simply view our entire LED matrix section!
Features
- 2048 individual RGB LEDs, full-colour display
- Adjustable brightness
- 64×32 pixels, 3mm pitch - display text, colourful images or animations
- 192x96mm dimensions - suitable for DIY desktop display or wall mount display
- Two HUB75 headers, one for controller data input, one for output (chain support)
- Demo code for use with Raspberry Pi Pico, Arduino and more
- 5V 2.5A power supply recommended
Specification
| Dimensions | 192mm × 96mm x 14.5mm |
| Pixels | 64x32 = 2048 LEDs |
| Pitch | 3mm |
| Pixel Form | 1R1G1B |
| Viewing Angle | ≥160° |
| Control Type | synchronization |
| Driving | 1/16 scan |
| Header | HUB75 |
| Power Supply | 5V / 2.5A（VH4 header input） |
| Power | ≤12W |
Resources
Pinout
| Pin | Description | Pin | Description |
| VCC | 5V power input | GND | Ground |
| R1 | R higher bit data | R2 | R lower bit data |
| G1 | G higher bit data | G2 | G lower bit data |
| B1 | B higher bit data | B2 | B lower bit data |
| A | A line selection | B | B line selection |
| C | C line selection | D | D line selection |
| E | E line selection | CLK | clock input |
| LAT/STB | latch pin | OE | output enable |
Package Contents
- 1x RGB-Matrix-P3-64x32 LED matrix and accessories
- 1x 16P wire ~30cm
- 1x Dark brown acrylic front panel
- 1x Power supply terminal adapter
- 1x Double-sided tape
- 4x Magnetic bolt
